PlugIn - EV Charger Sharing Platform

A native iOS application that connects electric vehicle drivers with EV charger hosts in their community, enabling a seamless peer-to-peer charger booking experience. Built with SwiftUI and Firebase, PlugIn bridges the gap between EV charging infrastructure scarcity and underutilized residential chargers.

---

Video Demo

Watch the full demo to see:

• Full driver flow: map navigation → filtering → booking
• Host flow: adding charger → managing requests
• Real-time updates demonstration
• Two-sided marketplace in action

---

Screenshots & Demo

Key Screens

Screenshot 1: Driver Map View

• Interactive map showing real-time charger locations with green pins
• Each pin displays available credits/hour for the charger
• Search location bar at the top for finding specific areas
• Filter button to refine chargers by type, connector, price, and availability
• Location indicator showing user's current position
• Tab navigation showing Map, Charger, and Profile tabs

Screenshot 2: Charger Detail View

• Detailed charger information (type: DC Fast Charge, connector: J1772 Type I)
• Charger specifications (max speed: 156.6 kW)
• Host address and distance from current location
• Pricing displayed in green credits per hour
• "Request Charge" button to initiate a booking
• Map preview showing exact charger location

Screenshot 3: Add Charger - Location Details

• Host dashboard header with "Add Charger" option
• Map displaying charger location with placement pin
• Street address field pre-populated with detected location
• "Current Location" button for quick location selection
• "Select on Map" button for manual location picking
• Hardware specifications section (Charger Type: Level 2, Max Speed: 7.2 kW)
• Connector Type dropdown for selecting compatible connectors

Screenshot 4: Location Picker

• Interactive map for precise charger location placement
• Green + marker showing selected position
• Instruction text: "Tap anywhere on the map to place your charger pin"
• "Use Center of Screen" button to confirm center location
• "Go to My Location" button to place at current GPS location
• Clean, intuitive interface for location selection

Screenshot 5: Host Dashboard

• "HOST MODE" header with "Dashboard" title
• Bell icon for incoming request notifications
• List of registered chargers with cards showing:
  • Availability toggle (green when available)
  • Charger address and location
  • Hardware specs (charging speed, connector type)
  • Credits earned count
  • Edit button to modify charger details
  • Delete button with destructive styling (red)
• Bottom tab navigation (Map, Charger, Profile)

Screenshot 6: Add Credits

• Credit purchase packages with different tiers:
  • 10 Credits for $4.99 (entry level)
  • 30 Credits for $9.99 (25% bonus credits)
  • 65 Credits for $19.99 (15% bonus credits)
  • 130 Credits for $34.99 (35% bonus credits)
• "MOST POPULAR" badge on the most purchased tier
• Bonus credit information displayed for each package
• "Why Buy Credits?" section explaining benefits:
  • Instant Charging
  • Better Value
  • Secure Payment
• Green "Purchase 10 Credits for $4.99" button for completing transaction

---

Project Overview

PlugIn is a two-sided marketplace iOS app that solves a real-world problem: EV drivers struggle to find available chargers, while many homeowners with chargers want to share them and earn credits. The app facilitates connections between these two groups through an intuitive, map-based interface.

Target Users

• Drivers: Users looking for nearby available EV chargers with real-time availability
• Hosts: EV charger owners who want to share their chargers and earn green credits

Problem Statement

• Limited public EV charging infrastructure in many regions
• Inefficient use of private residential chargers
• Lack of seamless, trustworthy platforms for peer-to-peer charger sharing
• Need for transparent pricing and availability management

Solution

PlugIn provides a unified platform where:

• Drivers can discover nearby chargers on a live map with filters
• Hosts can manage their chargers and respond to booking requests in real-time
• Both parties can track booking history, ratings, and credits

---

Key Features

For Drivers

• Interactive Map View: Real-time charger discovery with location-based search
• Advanced Filtering: Filter by charger type, connector type, credits per hour, and availability schedule
• Location Services: One-tap "current location" and real-time distance calculations
• Booking System: Request charger bookings with estimated duration and immediate feedback
• Green Credits System: Purchase and track credit balance for charger usage
• Booking History: View past requests grouped by date with status tracking
• Rating System: Rate chargers and provide feedback after usage
• Profile Management: Upload profile photos, manage account settings, privacy controls

For Hosts

• Charger Management: Register and manage multiple EV chargers with detailed specs
• Availability Scheduling: Set weekly availability schedule with specific hours
• Request Management: Real-time notifications and quick accept/decline functionality
• Dashboard Analytics: Track total bookings, earnings, and charger performance
• Pricing Control: Set custom credit rates per charger
• Host Verification: Verified badge display to build trust
• Request Sheet UI: Streamlined interface for managing incoming booking requests

Core Cross-Platform Features

• Firebase Authentication: Email/password signup and signin with persistent sessions
• Real-time Data Sync: Firestore listeners for instant updates across devices
• Photo Management: Firebase Storage integration for profile and charger images
• Geo-location: CoreLocation integration with GeoPoint storage in Firestore
• Responsive Design: Optimized for iPhone and iPad with portrait orientation support

---

Architecture & Technical Design

Architecture Pattern

The app follows a Clean Architecture with clear separation of concerns:

PlugIn/
├── App/                           # App entry point & lifecycle
├── Configuration/                 # Build & environment config
├── Core/
│   ├── Services/                 # Business logic services
│   │   ├── Firebase/             # Auth, Firestore, Storage
│   │   └── Location/             # CoreLocation wrapper
│   ├── Navigation/               # Routing & coordination
│   ├── Components/               # Reusable UI components
│   └── Utilities/
│       ├── Extensions/           # Swift extensions
│       ├── Helpers/              # Formatting, validation
│       └── Constants/
├── Domain/
│   ├── Models/                   # Codable data structures
│   ├── Enums/                    # Type-safe enumerations
│   └── Repositories/             # Data access layer
└── Views/
    ├── Root/                     # Navigation & tab views
    ├── Authentication/           # Sign-up flows
    ├── Driver/                   # Map & charger discovery
    ├── Booking/                  # Booking flows
    ├── AddCharger/               # Host charger registration
    ├── HostDashboard/            # Host management interface
    ├── Request/                  # Booking requests handling
    ├── Profile/                  # User account management
    └── Common/Components/        # Shared UI components

Design Patterns Used

1. MVVM (Model-View-ViewModel)

   • Each screen has a corresponding @MainActor ViewModel
   • Two-way binding via @Published properties
   • Example: DriverMapViewModel, BookingViewModel, HostDashboardViewModel

2. Repository Pattern

   • ChargerRepository & BookingRepository abstract Firestore operations
   • Enables testing and data source flexibility
   • Single source of truth for data access

3. Coordinator Pattern

   • AppCoordinator manages navigation state and sheet presentations
   • Centralized routing logic (type-safe NavigationDestination enum)
   • Decouples views from navigation responsibilities

4. Service Layer

   • AuthService: Manages Firebase Auth state with persistent listeners
   • FirestoreService: Centralized Firestore operations
   • LocationService: Abstracts CoreLocation functionality
   • FirebaseStorageService: Handles image uploads/downloads

5. Environment Objects

   • AuthService, LocationService, and AppCoordinator passed via SwiftUI environment
   • Global access without prop drilling

---

Technology Stack

Frontend

• SwiftUI: Modern declarative UI framework (iOS 16+)
• MapKit: Interactive map with custom pin annotations
• CoreLocation: Location tracking and permissions handling
• Combine: Reactive programming for data binding

Backend & Services

• Firebase Authentication: Email/password authentication with state persistence
• Firestore Database: Real-time NoSQL database with listeners
• Firebase Storage: Cloud storage for user profile and charger images
• Firebase Core: Foundation for all Firebase services

Development Tools

• Xcode: IDE and project management
• Swift Package Manager: Dependency management
• Firebase iOS SDK: Cocoapods/SPM integration
• Git: Version control

Deployment

• iOS 16.0+: Minimum deployment target
• Universal App: Optimized for iPhone and iPad

---

Key Technical Challenges & Solutions

Challenge 1: Real-time Data Synchronization

Problem: Multiple users viewing the same chargers and bookings needed instant updates without stale data.

Solution:

• Implemented Firestore snapshot listeners in repositories and services
• AuthService maintains persistent auth state listener with race condition handling
• DriverMapViewModel auto-refreshes charger list with filter reapplication
• Implemented @MainActor dispatch to ensure UI updates on main thread safely

Code Location: Core/Services/Firebase/AuthService.swift:122-148

private func listenToUserData(uid: String) {
    userListener = Firestore.firestore().collection("users").document(uid)
        .addSnapshotListener { [weak self] snapshot, error in
            // Real-time user data updates
        }
}

---

Challenge 2: Location-Based Search with Filtering

Problem: Efficiently filtering chargers by multiple criteria (type, connector, price, availability) while maintaining map performance and user location accuracy.

Solution:

• Implemented client-side filtering in DriverMapViewModel with applyFilters() method
• Stored GeoPoint in Firestore for distance calculation
• LocationService with distance filter (10m) to reduce location update frequency
• Computed availability checking based on weekly schedule using func isAvailable(at: Date)
• Filtered out user's own chargers to prevent self-booking

Code Location: ViewModel/Driver/DriverMapViewModel.swift:57

func applyFilters() {
    var filtered = allChargers

    // Filter by charger type, connector, max credits, and availability
    filtered = filtered.filter { $0.isAvailable(at: Date()) }

    self.chargers = filtered
}

---

Challenge 3: Two-Role User Management

Problem: Users could be both drivers AND hosts, requiring dynamic role-based UI and state management.

Solution:

• User model includes roles: [UserRole] array allowing multiple roles
• Computed properties: isHost, isDriver, hasSelectedRoles
• AuthService.addHostRole() seamlessly adds host role when user registers first charger
• MainTabView conditionally shows Driver Map or Host Dashboard based on role
• Firestore updates maintain role array without affecting other user data

Code Location: Domain/Models/User.swift:20-22

var isHost: Bool { roles.contains(.host) }
var isDriver: Bool { roles.contains(.driver) }
var hasSelectedRoles: Bool { !roles.isEmpty }

---

Challenge 4: Image Upload & Management

Problem: Async image uploads to Firebase Storage while maintaining UI responsiveness and handling errors gracefully.

Solution:

• FirebaseStorageService abstracts upload/download logic
• UI shows loading spinner during upload (isUploadingImage flag)
• Separate error handling with user-facing messages
• Profile image cached via AsyncImage in SwiftUI
• Storage paths follow user hierarchy (users/{uid}/profile.jpg)

Code Location: Views/Profile/ProfileView.swift:39-57

if !isUploadingImage {
    Button(action: { showImagePicker = true }) {
        // Camera button
    }
} else {
    ProgressView() // Loading state
}

---

Challenge 5: Availability Scheduling & Validation

Problem: Complex availability scheduling with weekly recurrence and hour ranges needing real-time validation during bookings.

Solution:

• DayAvailability struct for each day of week (0-6) with startHour/endHour
• Charger.isAvailable(at: Date) computed method checks schedule availability
• AddChargerView provides hour picker for intuitive schedule setup
• Availability can be disabled for specific days (vacation mode)
• Booking system respects availability constraints in real-time

Code Location: Domain/Models/Charger.swift:53-61

func isAvailable(at date: Date) -> Bool {
    guard let schedule = availabilitySchedule else { return true }
    let weekday = (calendar.component(.weekday, from: date) - 1)
    let hour = calendar.component(.hour, from: date)
    guard let daySchedule = schedule.first(where: { $0.day == weekday }) else { return true }
    return daySchedule.isAvailable && hour >= daySchedule.startHour && hour < daySchedule.endHour
}

---

Challenge 6: Booking State Management

Problem: Bookings have multiple states (pending, accepted, active, completed, cancelled) requiring clear state transitions and preventing invalid operations.

Solution:

• BookingStatus enum with explicit states
• Booking model with computed isActive property
• BookingViewModel manages state transitions safely
• Real-time listeners notify both driver and host of status changes
• Timestamps track request→acceptance→start→end flow

Code Location: Domain/Models/Booking.swift:22-24

var isActive: Bool {
    status == .accepted || status == .active
}

---

Challenge 7: Portrait Orientation Lock (Multi-Device Support)

Problem: App needed to support both iPhone and iPad while maintaining consistent portrait-only orientation across devices.

Solution:

• AppDelegate configures supportedInterfaceOrientations for all view controllers
• Used info.plist device orientation settings
• Portrait constraint applied universally at app start
• Tested on both iPhone SE and iPad Air form factors

---

Data Models

User Model

struct User: Codable, Identifiable {
    var id: String?
    let email: String
    var name: String
    var roles: [UserRole]        // Can be driver, host, or both
    var greenCredits: Int
    var profileImageURL: String?
    var phoneNumber: String?

    // Host-specific fields
    var isVerified: Bool?
    var totalBookings: Int?
    var rating: Double?

    // Timestamps
    var createdAt: Timestamp
}

Charger Model

struct Charger: Codable, Identifiable, Hashable {
    var id: String?
    let hostId: String
    var location: GeoPoint
    var address: String
    var type: ChargerType                    // Level 1, Level 2, DC Fast Charging
    var connectorType: ConnectorType         // Tesla, CCS, CHAdeMO, J1772
    var pricePerHour: Double
    var creditsPerHour: Int
    var status: ChargerStatus                // Active, Inactive, Maintenance
    var maxSpeed: Double
    var hasTetheredCable: Bool
    var accessInstructions: String?
    var currentBookingId: String?
    var rating: Double
    var totalBookings: Int
    var availabilitySchedule: [DayAvailability]?  // Weekly schedule with hours
}

Booking Model

struct Booking: Codable, Identifiable, Hashable {
    var id: String?
    let chargerId: String
    let hostId: String
    let driverId: String
    var status: BookingStatus                // Pending, Accepted, Active, Completed, Cancelled
    var requestedAt: Timestamp
    var acceptedAt: Timestamp?
    var startedAt: Timestamp?
    var endedAt: Timestamp?
    var estimatedDuration: TimeInterval
    var creditsUsed: Int?
    var amountPaid: Double?
    var driverRating: Int?
    var hostRating: Int?
    var scheduledStartTime: Timestamp?       // For future bookings
}

---

UI/UX Highlights

Component Architecture

• Reusable Components: PrimaryButton, SecondaryButton, DestructiveButton
• Custom Forms: CustomTextField, CustomDropdown with validation
• Status Badges: StatusBadge, VerifiedBadge for visual hierarchy
• Loading States: LoadingView, SkeletonView for async operations
• Error Handling: ErrorView with retry functionality
• Cards: ChargerCard, StatsCard for consistent data display

Views & Flows

Screen	Purpose	Key Features
DriverMapView	Charger discovery	Interactive map, search, filters, real-time pins
ChargerDetailSheet	Charger information	Specs, availability, host rating, booking button
BookingRequestView	Booking creation	Duration picker, estimated credits, confirmation
HostDashboardView	Host management	Charger list, analytics, incoming requests bell
AddChargerView	Charger registration	Type selection, location picker, availability setup
RequestsListSheet	Incoming bookings	Real-time request notifications with accept/decline
ProfileView	User account	Profile photo, credits, booking history, settings
PastRequestsView	Booking history	Grouped by date, sortable, ratable

---

Project Evolution

Recent Commits

• Portrait orientation enforcement across iPhone and iPad
• AboutView with app info and feature highlights
• PastRequestsView with booking history grouped by date
• AddCreditsView with credit packages and demo payment flow
• PrivacySettingsView for user privacy controls

---

Getting Started for Developers

Prerequisites

• Xcode 15.0 or later
• iOS 16.0 deployment target
• CocoaPods or Swift Package Manager
• Firebase project setup

Setup Instructions

1. Clone the repository

   git clone <repository-url>
   cd PlugIn

2. Install Firebase

   # If using Cocoapods
   pod install
   # Or use SPM via Xcode

3. Configure Firebase

   • Download GoogleService-Info.plist from Firebase Console
   • Add to Xcode project
   • Enable Authentication (Email/Password)
   • Enable Firestore Database (test mode for development)
   • Enable Storage

4. Open Project

   open PlugIn/PlugIn.xcworkspace

5. Build & Run

   • Select simulator or device
   • Press Cmd+R

---

Testing

Manual Testing Scenarios

Driver Flow

1. Sign up as driver
2. Grant location permission
3. View chargers on map
4. Apply filters by type/connector/price
5. Tap charger pin → view details
6. Request booking → confirm duration
7. View past bookings → rate charger

Host Flow

1. Sign up as driver first
2. Switch to Host Dashboard
3. Add charger → select type, set location, availability, price
4. Receive booking requests (real-time notification)
5. Accept/decline requests from RequestsList
6. View charger analytics and ratings

Edge Cases Tested

• No permission → location prompts flow
• Network offline → error views
• Expired auth tokens → sign-out and re-auth
• Charger availability schedule → filters correctly
• Two-role users → seamless role switching
• Image upload failures → graceful error handling

---

Security & Privacy

Security Measures

• Firebase Auth: Secure email/password authentication with email verification
• Firestore Security Rules: Role-based access control (users can only see their own bookings and other hosts' public chargers)
• Storage Security: Private file paths with user ID isolation
• HTTPS: All Firebase communication encrypted in transit

Privacy Features

• PrivacySettingsView: Control data visibility
• Location Tracking: Only active when in-use (CoreLocation setting)
• Phone Number: Optional and private
• Booking History: User-specific access only

---

Learning Outcomes & Highlights

SwiftUI & iOS Development

• Modern declarative UI with SwiftUI (no UIKit)
• MapKit integration with custom annotations
• CoreLocation for real-time location tracking
• Combine framework for reactive programming
• Responsive design for multiple device sizes

Backend & Database

• Firebase Authentication flow with persistent sessions
• Firestore real-time listeners with snapshot listeners
• GeoPoint for location-based queries
• Firebase Storage for file management
• Document relationships and data modeling

Software Architecture

• Clean Architecture separation of concerns
• MVVM pattern with @Published and @ObservedObject
• Repository pattern for data access abstraction
• Coordinator pattern for navigation
• Service layer for business logic

Product & UX

• Two-sided marketplace design
• Real-world problem solving
• Intuitive user flows for both drivers and hosts
• Real-time notifications and updates
• Error handling and edge case management

---

Future Enhancements

Planned Features

• Push notifications for booking requests and status updates
• In-app messaging between drivers and hosts
• Payment integration (Stripe/Apple Pay) for credit purchases
• Review and rating system with photo uploads
• Favorites/bookmarked chargers list
• Charger availability calendar view
• Host verification with document upload
• Analytics dashboard with graphs and trends
• Multi-language support
• Dark mode support

Technical Improvements

• Unit tests with XCTest and mock services
• UI tests for critical user flows
• Performance optimization for large charger lists
• Offline mode with local caching
• App Store distribution setup
• CI/CD pipeline with GitHub Actions

---

Contributing

This project demonstrates production-level iOS development practices. Key architectural decisions and code organization are optimized for:

• Scalability: Easy to add new features without breaking existing code
• Maintainability: Clear separation of concerns and consistent patterns
• Testability: Service layer abstraction enables unit testing
• Code Quality: No force-unwrapping, proper error handling, type safety

---

Contact & Support

For questions about the code architecture, technical decisions, or feature implementation, please reach out to the developer.

---

License

This project is proprietary and intended for portfolio and learning purposes.

---

Summary for Recruiters

PlugIn is a full-featured iOS marketplace application that demonstrates:

1. Complete Product Development: From concept to features to real-world problem solving
2. Modern iOS Development: SwiftUI, Combine, CoreLocation, MapKit
3. Scalable Architecture: Clean Architecture, MVVM, Repository, Coordinator patterns
4. Backend Integration: Firebase (Auth, Firestore, Storage) with real-time sync
5. User-Centric Design: Two-sided marketplace with role-based features
6. Problem-Solving: Location-based filtering, state management, real-time updates
7. Code Quality: Type safety, proper error handling, separation of concerns
8. Responsive Design: Multi-device support (iPhone, iPad) with orientation control

Perfect demonstration of: Production-level Swift development, architectural thinking, and full-stack mobile application building.
